colour:
Red
frame:
Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg
fork:
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg
wheel size:
20" wheels
brakes:
Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads
shifters:
Shimano Deore, 1 x 10 spd
front derailleur:
N/A
rear derailleur:
Shimano Deore Shadow+
crankset:
Tern GSD custom, forged 6061-AL DH crankarm
cassette/freewheel:
Shimano 11-36T, 10 spd
chain:
10 spd, DHT for eBike, GST corrosion resistant coating
number of gears:
10
bottom bracket:
Motor integrated
motor
Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
battery
Bosch Dual Battery system, 400 Wh/900 Wh
wheelset:
Tern Atlas, ultra wide 36 mm, dual reinforced joint
tyres:
F: Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex
handlebars:
Tern Sweep, 6061-AL, Tern Andros adapted
stem:
Tern Andros, adjustable, forged construction, patented technology
bar tape/grips:
Ergon
saddle:
Tern GSD by Velo, with rear handle
seat post:
Tern Telescope, 34.9/30.9 mm, 2014-AL
pedals:
Urban with non-slip surface, sealed bearings
kickstand:
Atlas Lockstand, w/ remote unlock, patented technology
