COLOUR
Matt uni-directional (UD) carbon with gloss black
CASSETTE
SRAM XS 1297, T-Type, 10-52T, 12 speed
FRAME
Uni-directional carbon mainframe and seatstays, tapered head tube, ISCG 2 guide mounts, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts
CHAIN
SRAM XX T-Type, 12 speed
FORK
Fox Float 34 Factory 29in, 140mm travel, 44mm offset, FIT4 damper, tapered steerer, 110mm x 15mm Boost Kabolt axle
CRANKSET
SRAM XX Isis Carbon, 165mm arms, XX Gen4 Direct Mount 32T chainring, T-Type Light eMTB
REAR SHOCK
Fox Float Factory, Evol LV, adjustable rebound and two position compression adjustment
BOTTOM BRACKET
N/A
HEADSET
FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) catridge bearings, with side entry internal routing
SEATPOST
KS Lev Ci, 30.9mm, 175mm drop, with Southpaw remote lever
REAR HUB
DT Swiss 240, e-bike specific, double sealed cartridge bearings, straight pull, 12mm x 148mm Boost spacing, six bolt, XD driver
SADDLE
Terra Aidon X1, 145mm, fibre reinforced nylon with Wingflex, Carbon 7x7mm rail
FRONT HUB
DT Swiss 240, straight pull, six bolt, 15mm x 110mm Boost spacing
HANDLEBAR
Race Face NEXT R Carbon, 20mm rise, 35mm bar bore, 800mm wide
SPOKES
DT Swiss Competition spokes straight pull (SP)
STEM
Whyte Trail full CNC, 40mm extension, 35mm bar bore
RIMS
DT Swiss XRC 1501 Spline
GRIPS
Whyte Enduro lock-on
TYRE
Good Year Escape tubeless ready tan wall 29in x 2.4in, 800g front and rear
BRAKES FRONT
SRAM Level Ultimate Stealth, four piston hydraulic, 180mm diameter disc rotor
SHIFT LEVERS
SRAM AXS Pod, right, MMX, 12 speed
BRAKES REAR
SRAM Level Ultimate Stealth, four piston hydraulic, 180mm diameter disc rotor
FRONT MECH
N/A
BRAKE LEVERS
SRAM Level Ultimate Stealth
REAR MECH
SRAM XX SL T-Type AXS, 12 speed
PEDALS
Fibre reinforced composite platform
WEIGHT
16.4kg (size M)
