COLOUR
Gloss olive with matt uni-directional (UD) carbon
CASSETTE
SRAM XS 1295, T-Type, 10-52T, 12 speed
FRAME
Uni-directional carbon mainframe and seatstays, tapered head tube, ISCG 2 guide mounts, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts
CHAIN
SRAM XO T-Type, 12 speed
FORK
Fox Float 36 Factory 29in, 150mm travel, 44mm offset, Grip2 damper, tapered steerer, 110m x 15mm Kabolt axle
CRANKSET
Hope E-Bike Cranks, 155mm length, Bosch mounting, 36T chainring T-type
REAR SHOCK
Fox Float X Factory Series, EVOL, lock out, 210mm x 50mm
BOTTOM BRACKET
N/A
HEADSET
FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) catridge bearings, with side entry internal routing
SEATPOST
Whyte drop.it II Adjust, 30.9mm (sizes S/M 140-170mm travel; sizes L/XL 170-200mm travel), MMX Paddle remote lever
REAR HUB
Hope Pro 5, six bolt, 12mm x 148mm Boost spacing, XD driver, 32 hole
SADDLE
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail
FRONT HUB
Hope Pro 5, six bolt, 15mm x 110mm Boost spacing, 28 hole
HANDLEBAR
Race Face Next R Carbon, 20mm rise, 35mm bar bore, 800mm width
SPOKES
DT Swiss New Champion 2.0mm, black stainless, brass nipples
STEM
Whyte Trail full CNC, 32mm extension, 35mm bar bore
RIMS
Whyte TeXtreme Innegra infused, carbon Trail rims, 28 hole front, 32 hole rear
GRIPS
Whyte Enduro lock-on
TYRE
Maxxis Minion DHF, EXO TR MaxxGripp 29in x 2.5in front; Maxxis Dissector, EXO+ TR MaxxTerra 29in x 2.4in, rear
BRAKES FRONT
Hope Tech4 V4, four piston hydraulic, 200mm diameter floating disc rotor
SHIFT LEVERS
SRAM AXS Pod, right, MMX, 12 speed
BRAKES REAR
Hope Tech4 V4, four piston hydraulic, 200mm diameter floating disc rotor
FRONT MECH
N/A
BRAKE LEVERS
Hope Tech 4
REAR MECH
SRAM XO T-Type AXS, 12 speed
PEDALS
Fibre reinforced composite platform
WEIGHT
19.2kg (size M)
