Wheel Size:
20" wheels
Speeds:
1 x 8
Weight:
14.3 kg (31.5 lb)
Folding Size:
42 x 81 x 73 cm (16.5" x 31.9" x 28.7")
Folding Time:
10 sec
Frame Sizes:
One size
Gear Inches:
27" - 83" (2.15 - 6.60 m)
Distance: Seatpost To Handlebar:
Min: 570 mm (22.4") Max: 640 mm (25.2")
Distance: Saddle To Pedal:
Min: 710 mm (28") Max: 960 mm (37.8")
Suggested Rider Height:
142 - 190 cm (4'8" - 6'3")
Max Gross Vehicle Weight:
120 kb (264 lb)
Max Rider Weight:
105 kg (230 lb)
Frame:
Tern Verge, hydroformed aluminium w/ smooth TIG welding, OCL+ joint, 3 patented technologies
Fork:
Tarsus, 6061-AL, hydroformed
Handlepost:
Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 350 mm
Stem:
Tern Andros, adjustable, forged construction, patented technology
Headset:
Flux Pro, angular contact bearings, Physis integrated
Handlebar:
Kinetix Comp, double-butted 6061-Al
Grips/Bar Tape:
Phorm, w/ bar end
Saddle:
Tern Porter+, patented GripPad design, PrimeGel padding
Seatpost:
Stasis by Syntace, 7050-Al, hard-anodized
Seatpost Clamp:
Syntace OverLock
Front Brake:
Shimano, hydraulic disc
Rear Brake:
Shimano, hydraulic disc
Brake Levers:
Shimano, hydraulic disc
Brake Cable & Housing:
Shimano, hydraulic
Front Hub:
BioLogic Joule 3 dynamo, disc
Rear Hub:
Shimano Alfine, 8 spd
Spokes And Nipples:
Stainless, double-butted
Rims:
Kinetix Comp, doublewall
Tires:
Schwalbe Big Apple 55-406, puncture protection, Reflex
Shifter(S):
Shimano Alfine, 1 x 8 spd
Crankset:
Gates Carbon Drive
Cassette/Freewheel:
Gates CDX, precision CNC machined cog
Bottom Bracket:
Cartridge, sealed bearings
Chain:
Gates Carbon Drive belt
Pedals:
MKS UB-LITE EZY, QR
Shifter Cable & Housing:
Shimano
Bell:
Pitch, brass
Kickstand:
Rear mount, Pletscher design
Clip System:
Magnetix 2.0
Luggage Socket:
Yes
Front Light:
Tern Valo 2, integrated, 41 lux/150 lumens
Rear Light:
Spanninga Pixeo XDS
Fenders:
SplashGuard, stainless hardware
Rack(S):
Tern Cargo Rack
