Sizes
27.5": XS, S 29": M, L
Colours
Gloss chrysocolla
Frame
ALUXX-grade aluminium, 120mm FlexPoint suspension
Fork
Giant STL 34, 140mm, Boost 15x110
Shock
Suntour Raidon R, 184x44, custom tuned for Liv
Handlebar
Giant Contact TR35, 20mm rise, alloy 27.5": XS: 730mm, S: 750mm 29": M: 750mm, L: 780mm
Grips
Giant Sole-O
Stem
Giant Contact, 35mm 27.5": XS: 40mm, S: 50mm 29": M: 50mm, L: 60mm
Seatpost
Giant Contact Switch dropper, remote 27.5": XS: 75mm travel / 30.9 x 295mm S: 100mm travel / 30.9 x 345mm 29": M: 125mm travel / 30.9 x 395mm L: 125mm travel / 30.9 x 345mm
Saddle
Liv Sylvia
Pedals
Pedals not supplied
Shifters
Shimano CUES SL-6000, 1x10
Front Derailleur
N/A
Rear Derailleur
Shimano CUES RD-U6000, Shadow +
Brakes
Shimano BR-MT200, hydraulic, Shimano RT-26 rotors [F]180mm, [R]180mm
Brake Levers
Shimano BL-MT201
Cassette
Shimano CUES CS-LG300, 11x48
Chain
Shimano CUES LG500
Crankset
Shimano CUES, FC-U6000-1, 30t 27.5": XS: 170mm, S: 170mm 29": M: 170mm, L: 170mm
Bottom Bracket
Shimano BB MT501, press fit
Rims
27.5": Giant AM 27.5, tubeless ready, sleeve-joint rim, 30mm inner width 29": Giant AM 29, tubeless ready, sleeve-joint rim, 30mm inner width
Hubs
Giant Tracker Performance Boost 15x110, sealed bearing [R] Giant Tracker Giant Sport 148x12
Spokes
Sapim
Tyres
27.5": [F] Maxxis Minion DHF 27.5x2.6, EXO, TR, tubeless [R] Maxxis Dissector 27.5x2.6, EXO, TR, tubeless 29": [F] Maxxis Minion DHF 29x2.5 WT, EXO, TR, tubeless [R] Maxxis Dissector 29x2.4 WT, EXO, TR, tubeless
Extras
Factory tubeless set up
Max Tyre Clearance
2.6"
Max Chainring Size
32t
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
