Sizes
XS and S: MX only M: 29" F&R out of the box, MX compatible
Colours
Raw Carbon/Chrome
Frame
Advanced-Grade Composite front and rear triangles, 150mm Maestro Suspension, flip chip – Maestro 3, integrated down tube storage
Fork
Fox 36 Performance Elite, 160mm, Grip damper, Boost, 15x110, Kabolt, tapered, 44mm offset
Shock
Fox Float X Performance Elite 185x55, custom tuned for Liv
Handlebar
Giant Contact SLR TR35, composite, 35mm, 20mm rise XS: 760mm, S: 760mm, M: 760mm
Grips
Liv Tactal Pro Single Lock-On XS and S: 110mm, M: 120mm
Stem
Giant Contact SL, 35mm XS: 40mm, S: 50mm, M: 50mm
Seatpost
TranzX travel-adjustable dropper, remote XS: 120-150mm travel / 30.9 x 459mm S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mm
Saddle
Liv Sylvia
Pedals
platform
Shifters
SRAM GX Eagle, 1x12
Front Derailleur
N/A
Rear Derailleur
SRAM GX Eagle
Brakes
SRAM G2 RSC, hydraulic, SRAM CenterLine rotors [F]200mm, [R]180mm
Brake Levers
SRAM G2 RSC
Cassette
SRAM GX Eagle, 10x52
Chain
SRAM GX
Crankset
SRAM GX, 30t, 55mm chainline XS: 165mm, S: 170mm, M: 170mm
Bottom Bracket
SRAM DUB, press fit
Rims
Giant TRX 2 29 WheelSystem, composite, 30mm inner width XS and S: [F] 29", [R] 27.5" M: [F] 29", [R] 29"
Hubs
[F] Giant MTB alloy, 6-bolt [R] Giant MTB alloy, 3-pawl driver, 6-bolt
Spokes
Sapim
Tyres
[Size XS, S and M, Front] Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless [Size XS and S, Rear] Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless [Size M Rear] Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
Extras
MRP AMg V2 chainguide, 3M tailgate protector, factory tubeless set up, max tire size 2.5", max chainring size 32t, integrated down tube storage bag
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
