Sizes
XS, S, M, L
Colours
Gloss Raw Carbon/Chrome
Frame
Advanced-grade composite front and rear triangles, 140mm Maestro Suspension, flip chip – Maestro 3, flip chip – headset, integrated down tube storage
Fork
Fox 36 Performance Elite, 150mm, Grip 2 damper, Boost 15x110 Kabolt X, tapered, 44mm offset
Shock
Fox Float X Performance Elite, 185x52.5, custom tuned for Liv
Handlebar
Giant Contact SLR TR35, 20mm rise, composite
Grips
Liv Tactal Pro Single Lock-on
Stem
Giant Contact SL, 35mm
Seatpost
Giant Contact Switch, adjustable dropper, remote XS&S: 140-170mm travel / 30.9 x 470mm M&L: 170-200mm travel / 30.9 x 530mm
Saddle
Liv Sylvia
Pedals
PEDALS NOT SUPPLIED
Shifters
SRAM AXS Pod, 1x12
Front Derailleur
N/A
Rear Derailleur
SRAM GX Eagle Transmission AXS
Brakes
Shimano XT M8120, hydraulic, Shimano RT-66 rotors [F] 203mm, [R] 180mm
Brake Levers
Shimano XT BL-8100
Cassette
SRAM GX CS 1275 T-Type, 10x52
Chain
SRAM GX T-Type
Crankset
SRAM GX T-Type, 30t, 55mm chainline
Bottom Bracket
SRAM DUB, press fit
Rims
Giant TRX 27.5""/29"" hookless carbon wheelsystem 30mm rim inner width 40mm outer width 72t, POE, 28 SP spokes, DBL technology XD driver body 27.5""R/29""F for frame sizes XS/S 29""F&R for frame sizes for M/L
Hubs
[F] Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt
Spokes
Sapim
Tyres
Size XS, S, M and L, [F]: Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless Size XS and S, [R]: Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless Size M and L, [R]: Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
Extras
3M tailgate protector, factory tubeless set up, integrated down tube storage bag, max tyre size 2.5", max chainring size 34t
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
